To complicate matters further, some of the spotting gene patterns can be combined to produce a horse with multiple color traits, such as the Tovero. The genetics of pinto spotting patterns are still being researched and are not fully understood. Some patterns may be polygenic, dominant, or incomplete dominants, and spoting can be so minimally expressed on an individual that the animal is mistaken for a "solid" colored horse. The sabino pattern is one of the most complex, as there has been one gene identified, SB-1, that creates one type of sabino patterning, but not all sabino-patterned horses carry it. There is a DNA test for the allele associated with the frame overo pattern, which causes the controversial lethal white syndrome, and there is a DNA test for three mutations, SW-1, SW-2, and SW-3, associated with splashed white.
Although the condition lethal white syndrome is also sometimes called "overo lethal white," that term is somewhat a misnomer. Because there are many different ways a horse can be classified as an "overo," and different genes linked to overo patterning, it is not accurate to say the "overo gene" is what "causes" lethal white syndrome. The frame allele is associated with lethal white, but the other genetics, such as horses with sabino and splash alleles, are not. There is a genetic link between splash white and deafness, but the correlation is not yet fully understood.
Frame overos have sharply defined, irregular, horizontally oriented white patches. As here, they are often bald-faced and white patches seldom cross the topline, creating a "frame" of non-white coat.
The frame overo pattern is the most common of the three types of overo patterns recognized in the American Paint Horse breed. A frame overo horse appears to be any solid base color (bay, black, chestnut, etc.) with white irregular patches added, usually with a horizontal orientation. Markings are often of jagged shape rather than rounded, the white rarely crosses the back, the lower legs tend to be dark, and the tail is one color, usually dark. The head is often white or bald-faced, and blue eyes are not uncommon. The frame overo pattern usually behaves like a dominant gene, in that when frame overo horses are crossed on nonspotted horses, about half of the foals come out spotted. There are records of frame overos being produced by two nonspotted parents. There is a theory, however, that these "solid" horses simply may be horses with very minimal expression of overo genetics.
Frame coloring is controversial because it is associated with lethal white syndrome (OLWS or LWS), the equine version of Hirschprung disease. LWS occurs when a foal is homozygous for the Ile118Lys EDNRB mutation, which is considered by many researchers to be "usually responsible" for the frame overo phenotype. However, other researchers emphasize that overo spotting patterns are phenotypically and genetically heterogeneous, that is, may have multiple sources.
The frame overo gene can be masked by other white patterns, particularly tobiano, which is a dominant gene and epistatic to overo. Epistatic means that when both genes are present, this is the one expressed.
In addition, some carriers of the LWS allele appear to be solid. One theory holds that such horses carry the frame gene, but so minimal in expression that they appear solid. Either way, all LWS foals have horses with frame overo patterning in their pedigrees, and horses carrying a frame allele may not necessarily have a visible expression of the frame overo color.
Foals which are homozygous for frame and thus have lethal white syndrome (LWS) are not albinos. Albinism does not exist in horses. LWS foals are born almost or completely white with pink skin, but have blue eyes, not red ones. The lethal trait is that the nerves of the foal's digestive system are undeveloped and the bowel cannot move food along. All lethal white foals die within 72 hours after birth, and are typically euthanized sooner for humane reasons. A horse can be a carrier of the trait when it carries only one copy of the gene, (that is, heterozygous) and carriers are healthy and show no clinical signs of lethal white syndrome.
Thus, it is recommended by organizations such as the American Paint Horse Association that horses of any pattern with overo ancestors be tested to verify their carrier state before being bred. There is a DNA test for the gene which can be used to plan breedings and avoid producing affected foals. The mutation has not been found in solid-colored horses from breeds without frame patterning. Likewise, a sick foal that happens to be white can be tested to avoid inadvertent euthanization of a non-lethal foal who has a simple case of colic.
Lethal white horses should not be confused with genetically white horses, nor with "fully expressed" white sabinos, any of which may also be completely white with pink skin. Blue-eyed, pink-skinned cremellos and other horses carrying the cream gene do not carry the LWS allele unless they also have an ancestor with overo genetics. The splash white and sabino genetics are not associated with lethal white, though such horses could also be carriers of the frame allele.
A splash or splashed white overo pattern appears like a solid-colored horse who has been dipped in white paint, and the color splashed up from the bottom. It is the least common of the overo patterns. The legs and bottom portion of the body are usually white, as is the head, and blue eyes are common. Edges where white and dark color meet are usually crisp and sharp. Recent studies suggest that splashed white may be caused by a dominant gene. Splash overos are more prone to being deaf than other horses.
Outside of the United States, the term "splash" is sometimes applied to horses of apparent Sabino patterning.
Sabino is listed a type of overo coloring by the American Paint Horse Association. This terminology, outdated in terms of modern genetics, creates confusion, because other breeds, including many that will not register "pinto" or "paint" horses, may have individuals with sabino genetics. One reason for the terminology confusion is that "overo" was used by Paint horse breeders in the United States to refer to "anything that is not tobiano." Another reason for this terminology is that the term "overo", when used outside of the USA, particularly in Spanish-speaking countries, refers to horses with the speckled roaningpatterns typical of horses called sabino in the USA. In addition, strongly marked sabino horses may mimic either overo or tobiano coloring.
In general, sabino is a generic description for a group of similar white spotting patterns. These include high white stockings on all four feet, often extending up the legs with jagged edges, a fairly white head, with markings often extending past the eyes, roaning at the edges of white markings, lip spots, "lacing," and white patches on the lower barrel that may extend to the flanks. A minimal sabino may only have one of the traits associated with sabino horses. On the other hand, a "sabino-white" is a near-white or completely white horse, and sabino genetics are not linked to lethal white.
Tobiano coloring is the inverse of Overo spotting. Tobianos have a vertical spotting pattern, large, rounded spots, white that crosses the topline, dark heads, but mostly white legs and white or multi-colored tail. Typical examples tend to have more white than dark, whereas typical frame overo horses tend to more dark than white, though there are many exceptions in both cases. It is created by a different gene from any of the overo patterns and is a dominant gene. All tobianos must have at least one tobiano parent. When a tobiano allele is present, it is epistatic and often masks other patterns.
Tovero and other mixed patterns
This horse has mostly frame overo characteristics, including a horizontal spotting pattern, white face, and dark tail, but it also has sabino traits of roaning, jagged white leg markings and lip spots. Thus, its coloring suggests it may carry both frame overo and sabino genetics.
A tovero horse has pinto spotting patterns that show characteristics of both overo and tobiano and probably carries genes for both. For example, a tovero might have tobiano body spotting with rounded edges and white across the back, yet have irregular facial markings and blue eyes.Horses may also have a combination of sabino and frame overo genetics or any other combination of genes, resulting patterns that are difficult to smoothly classify into any one group.
